RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Circular Connectors
Description QUICKON plug-in connector series QPD P Number of pins: 4 1403782 Phoeni
PDF
/
Buying Options
Total Price: USD $16.84
Unit Price: USD $16.837547
≥1 USD $16.837547
≥10 USD $15.884478
≥100 USD $14.985353
≥500 USD $14.137126
≥1000 USD $13.336909
Inventory: 3376
Minimum: 1
-
+

Technical Details

Compliance

Ratings IP68
RoHS Status RoHS Compliant
Material Flammability Rating UL94 V-0

Dimensions

Length 87.8mm

Technical

Cable Opening 0.354 ~ 0.630 (9.00mm ~ 16.00mm)
Number of Contacts 5
Current Rating 20A
Ingress Protection IP66/68/69K - Dust Tight, Water Resistant, Waterproof
Contact Finish - Mating Silver
Fastening Type Threaded
Voltage - Rated 1kV
Color Black, Gray
Number of Positions 5 (4 + PE)
Connector Type Distributor
Termination IDC
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Backshell
Series QPD
Published 2015
Packaging Bulk
Operating Temperature -40°C~100°C

Physical

Backshell Material, Plating Polyamide (PA), Nylon
Insert Material Polyamide (PA), Nylon
Housing Material Polyamide
Shell Material Polyamide (PA), Nylon
Number of Pins 4
Mounting Type Free Hanging (In-Line)
Mount Plug-In
Contact Material Copper

Supply Chain

Factory Lead Time 4 Weeks
