820K006-273L401
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
CONN RCPT FMALE 6POS SOLDER CUP
PDF
/
Inventory: 8652
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Contact Material Copper Alloy
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material Brass
Insert Material Polyphenylene Sulfide (PPS)
Backshell Material, Plating Brass, Chrome
Technical
Operating Temperature -40°C~200°C
Packaging Tray
Published 2016
Series QUIK-LOQ? 820K
Feature Backshell, Strain Relief
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder Cup
Connector Type Receptacle, Female Sockets
Number of Positions 6
Color Black, Silver
Applications Industrial, Instrumentation, Medical, Testing Equipment & Measurement, Telecommunications
Voltage - Rated 280V
Fastening Type Push-Pull
Contact Finish - Mating Gold
Current Rating (Amps) 2.5A
Orientation Keyed
Shielding Shielded
Ingress Protection IP67 - Dust Tight, Waterproof
Shell Finish Nickel
Cable Opening 0.130 ~ 0.165 (3.30mm ~ 4.20mm)
Dimensions
Contact Finish Thickness - Mating 7.00μin 0.178μm
Compliance
RoHS Status ROHS3 Compliant
Ratings Dust Tight, IP67, Waterproof
