PSA.2E.310.CLLC80
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Push Pull Connectors 10P PNL MT SLDR REC FEM 8.2mm CBL COLLET
PDF
/
Inventory: 9835
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Brass, Bronze
Mount Bulkhead, Free Hanging, Panel, Rear Side Nut
Mounting Type Free Hanging (In-Line); Panel Mount
Mounting Feature Bulkhead - Rear Side Nut
Shell Material Brass
Insert Material Polyetheretherketone (PEEK)
Backshell Material, Plating Brass, Chrome
Technical
Operating Temperature -55°C~200°C
Packaging Bulk
Series 2E
Feature Backshell
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder Cup
Connector Type Receptacle, Female Sockets and Male Pins
Number of Positions 10
Color Silver
Fastening Type Push-Pull
Contact Finish - Mating Gold
Orientation Keyed
Shielding Shielded
Ingress Protection IP66/68 - Dust Tight, Water Resistant, Waterproof
Current Rating 7A
Shell Finish Chrome
Shell Size - Insert 310
Cable Opening 0.299 ~ 0.315 (7.60mm ~ 8.00mm)
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Ratings Dust Tight, IP66, Water Resistant, Waterproof
