PRG.M1.4GL.LC39J
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
1P ROHS3Compliant IP50 G Circular Connector -50C~150C 2A
PDF
/
Inventory: 6528
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings IP50
RoHS Status ROHS3 Compliant
Technical
Cable Opening 0.106 ~ 0.154 (2.70mm ~ 3.90mm)
Shell Size - Insert M14
Current Rating 2A
Ingress Protection IP50 - Dust Protected
Shielding Unshielded
Orientation G
Contact Finish - Mating Gold
Fastening Type Push-Pull, Detent Lock
Applications Automotive, Industrial, Medical, Testing Equipment & Measurement
Color Gray, Yellow
Number of Positions 14
Connector Type Receptacle, Female Sockets
Termination Solder Cup
Part Status Active
Pbfree Code yes
Feature Backshell
Series 1P
Packaging Bulk
Operating Temperature -50°C~150°C
Physical
Backshell Material, Plating Polysulfone (PSU)
Insert Material Polyetheretherketone (PEEK)
Shell Material Polysulfone (PSU)
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material NOT SPECIFIED
