PMN.2M.312.XLMT

LEMO
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Circular Connectors
Description POLARIZED Circular Connector
PDF
/
Buying Options
Total Price: USD $72.16
Unit Price: USD $72.16
≥1 USD $72.16
≥10 USD $66.22088
≥100 USD $63.673632
≥500 USD $61.551248
≥1000 USD $58.15524
Inventory: 13
Minimum: 1
-
+

Technical Details

Compliance

Ratings Dust Tight, IP68, Waterproof
RoHS Status ROHS3 Compliant

Dimensions

Contact Finish Thickness - Mating 59.0μin 1.50μm

Technical

Cable Opening 0.512 (13.00mm)
Environmental Characteristics FLUID/VIBRATION RESISTANT
Backshell Type SOLID
Empty Shell NO
Mating Information MULTIPLE MATING PARTS AVAILABLE
Shell Size - Insert 312
Shell Finish Nickel
Current Rating 7A
Ingress Protection IP68 - Dust Tight, Waterproof
Shielding Shielded
Orientation N (Normal)
Total Number of Contacts 12
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Gold
Fastening Type Threaded
Additional Feature POLARIZED
Applications Aerospace, Automotive, Aviation, Military
Color Gray
Number of Positions 12
Connector Type Receptacle, Female Sockets
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series 2M
Packaging Bulk
Operating Temperature -55°C~200°C

Physical

Insert Material Polyetheretherketone (PEEK)
Shell Material Aluminum Alloy
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Bronze
