PKJ.3B.318.CYCD12

LEMO
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Circular Connectors
Description Circular Connector
PDF
/
Inventory: 6844
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0

Dimensions

Contact Finish Thickness - Mating 39.4μin 1.00μm
Length 56mm
Diameter 25mm

Technical

Cable Opening 0.425 ~ 0.469 (10.80mm ~ 11.90mm)
Contact Style Pin
Shell Size - Insert 318
Shell Finish Chrome
Current Rating 7A
Ingress Protection IP50 - Dust Protected
Shielding Shielded
Orientation J
Contact Finish - Mating Gold
Fastening Type Push-Pull
Gender Female
Color Silver
Number of Positions 18
Connector Type Receptacle, Male Pins
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Backshell
Series 3B
Packaging Bulk
Operating Temperature -55°C~250°C

Physical

Backshell Material, Plating Brass, Chrome
Insert Material Polyetheretherketone (PEEK)
Shell Material Brass
Mounting Feature Bulkhead - Rear Side Nut
Mounting Type Free Hanging (In-Line); Panel Mount
