PKG.0B.303.CLLD42
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Push Pull Connectors RTD1 3 PIN RECEPT
PDF
/
Inventory: 2908
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings IP50
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Mating 59.0μin 1.50μm
Length 35.5mm
Diameter 12.4mm
Technical
Cable Opening 0.126 ~ 0.165 (3.20mm ~ 4.20mm)
Coupling Type SNAP
Contact Style Socket
Shell Size - Insert 303
Shell Finish Chrome
Current Rating 8A
Ingress Protection IP50 - Dust Protected
Shielding Shielded
Orientation G
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Gold
Fastening Type Push-Pull
Gender Female
Color Silver
Number of Positions 3
Connector Type Receptacle, Female Sockets
ECCN Code EAR99
Termination Solder Cup
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Backshell
Series 0B
Packaging Bulk
Operating Temperature -55°C~250°C
Physical
Backshell Material, Plating Brass, Chrome
Insert Material Polyetheretherketone (PEEK)
Shell Material Brass
Mounting Feature Bulkhead - Rear Side Nut
Mounting Type Free Hanging (In-Line); Panel Mount
Mount Bulkhead, Free Hanging, Panel, Rear Side Nut
Contact Material Bronze
