PHJ.2B.303.CYCD82Z
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Connector
PDF
/
Inventory: 3638
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings IP50
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Mating 39.4μin 1.00μm
Length 46mm
Diameter 16.5mm
Technical
Cable Opening 0.283 ~ 0.323 (7.20mm ~ 8.20mm)
Contact Style Pin
Shell Size - Insert 303
Shell Finish Chrome
Current Rating 17A
Ingress Protection IP50 - Dust Protected
Shielding Shielded
Orientation J
Contact Finish - Mating Gold
Fastening Type Push-Pull
Gender Male
Color Silver
Number of Positions 3
Connector Type Receptacle, Male Pins
Termination Crimp
Part Status Active
Feature Backshell
Series 2B
Packaging Bulk
Operating Temperature -55°C~250°C
Physical
Backshell Material, Plating Brass, Chrome
Insert Material Polyetheretherketone (PEEK)
Shell Material Brass
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
