PHJ.2B.302.CLAD92Z
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Connector
PDF
/
Inventory: 9230
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material NOT SPECIFIED
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material Brass
Insert Material Polyetheretherketone (PEEK)
Backshell Material, Plating Brass, Chrome
Technical
Operating Temperature -55°C~250°C
Packaging Bulk
Series 2B
Feature Backshell
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder Cup
Connector Type Receptacle, Male Pins
Number of Positions 2
Color Silver
Gender Male
Fastening Type Push-Pull
Contact Finish - Mating Gold
Orientation J
Shielding Shielded
Ingress Protection IP50 - Dust Protected
Current Rating 25A
Shell Finish Chrome
Shell Size - Insert 302
Contact Style Pin
Cable Opening 0.323 ~ 0.362 (8.20mm ~ 9.20mm)
Dimensions
Diameter 16.5mm
Length 46mm
Contact Finish Thickness - Mating 39.4μin 1.00μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Ratings IP50
