PHJ.1B.306.CYCD52
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Push Pull Connectors 6P FREE RCPT CRIMP CABLE COLLET 5.2MM
PDF
/
Inventory: 4072
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material Brass
Insert Material Polyetheretherketone (PEEK)
Backshell Material, Plating Brass, Chrome
Technical
Operating Temperature -55°C~250°C
Packaging Bulk
Series 1B
Feature Backshell
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Receptacle, Male Pins
Number of Positions 6
Color Silver
Gender Male
Fastening Type Push-Pull
Contact Finish - Mating Gold
Orientation J
Shielding Shielded
Ingress Protection IP50 - Dust Protected
Current Rating 7A
Shell Finish Chrome
Shell Size - Insert 306
Contact Style Pin
Cable Opening 0.165 ~ 0.205 (4.20mm ~ 5.20mm)
Dimensions
Diameter 12.5mm
Length 39.5mm
Contact Finish Thickness - Mating 39.4μin 1.00μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Ratings IP50
