PHG.XB.322.CLLD82

LEMO
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Circular Connectors
Description Circular Push Pull Connectors 22P FREE RCPT SOLDER CABLE COLLET 8.2MM
PDF
/
Inventory: 2160
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Contact Material Bronze
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material Brass
Insert Material Polyetheretherketone (PEEK)
Backshell Material, Plating Brass, Chrome

Technical

Operating Temperature -55°C~250°C
Packaging Bulk
Series XB
Feature Backshell
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder Cup
Connector Type Receptacle, Female Sockets
Number of Positions 22
Color Silver
Gender Female
Fastening Type Push-Pull
Contact Finish - Mating Gold
Orientation G
Shielding Shielded
Ingress Protection IP50 - Dust Protected
Current Rating 1.5A
Shell Finish Chrome
Shell Size - Insert 322
Contact Style Socket
Cable Opening 0.291 ~ 0.315 (7.40mm ~ 8.00mm)

Dimensions

Diameter 13mm
Length 49.5mm
Contact Finish Thickness - Mating 59.0μin 1.50μm

Compliance

Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Ratings IP50
