PHG.3B.320.CLLD92
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Push Pull Connectors 20P FREE RCPT SOLDER CABLE COLLET 9.2MM
PDF
/
Inventory: 1870
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings IP50
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Mating 59.0μin 1.50μm
Length 54.5mm
Diameter 19mm
Technical
Cable Opening 0.303 ~ 0.362 (7.70mm ~ 9.20mm)
Contact Style Socket
Shell Size - Insert 320
Shell Finish Chrome
Current Rating 6A
Ingress Protection IP50 - Dust Protected
Shielding Shielded
Orientation G
Contact Finish - Mating Gold
Fastening Type Push-Pull
Gender Female
Color Silver
Number of Positions 20
Connector Type Receptacle, Female Sockets
Termination Solder Cup
Part Status Active
Pbfree Code yes
Feature Backshell
Series 3B
Packaging Bulk
Operating Temperature -55°C~250°C
Physical
Backshell Material, Plating Brass, Chrome
Insert Material Polyetheretherketone (PEEK)
Shell Material Brass
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Bronze
