PHG.2B.316.CLLD82
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Push Pull Connectors 16P RECEPTACLE FEMALE SOLDER
PDF
/
Buying Options
Total Price: USD $75.31
Unit Price: USD $75.3104
≥1 USD $75.3104
≥10 USD $69.10464
≥100 USD $66.446688
≥500 USD $64.231728
≥1000 USD $60.687968
Inventory: 49
Minimum: 1
-
+
Technical Details
Compliance
Ratings IP50
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Mating 59.0μin 1.50μm
Length 46mm
Diameter 16.5mm
Technical
Cable Opening 0.283 ~ 0.323 (7.20mm ~ 8.20mm)
Wire/Cable Gauge 22 AWG
Contact Style Socket
Contact Gender Female
Voltage - Rated AC 950V
Shell Size - Insert 316
Shell Finish Chrome
Current Rating 6A
Ingress Protection IP50 - Dust Protected
Shielding Shielded
Orientation G
Contact Finish - Mating Gold
Voltage - Rated DC 1.34kV
Fastening Type Push-Pull
Color Silver
Number of Positions 16
Connector Type Receptacle, Female Sockets
Termination Solder Cup
Part Status Active
Feature Backshell
Series 2B
Packaging Bulk
Operating Temperature -55°C~250°C
Physical
Backshell Material, Plating Brass, Chrome
Insert Material Polyetheretherketone (PEEK)
Shell Material Brass
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Bronze
