PHG.2B.307.CLLD72Z
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Push Pull Connectors 7P SOLDER SCKT RECPT CABLE COLLET 7.2MM
PDF
/
Inventory: 927
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Series 2B
Feature Backshell
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder Cup
Connector Type Receptacle, Female Sockets
Number of Positions 7
Color Silver
Gender Female
Fastening Type Push-Pull
Contact Finish - Mating Gold
Orientation G
Shielding Shielded
Ingress Protection IP50 - Dust Protected
Current Rating 11A
Shell Finish Chrome
Shell Size - Insert 307
Contact Style Socket
Cable Opening 0.244 ~ 0.283 (6.20mm ~ 7.20mm)
Packaging Bulk
Operating Temperature -55°C~250°C
Dimensions
Diameter 16.5mm
Length 46mm
Contact Finish Thickness - Mating 59.0μin 1.50μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Ratings IP50
Physical
Backshell Material, Plating Brass, Chrome
Insert Material Polyetheretherketone (PEEK)
Shell Material Brass
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Bronze
