PHG.1K.306.CLLC55Z
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
LEMO PHG.1K.306.CLLC55Z Circular Connector, 1K Series, Cable Mount Receptacle, 6 Contacts, Solder Socket, Push-Pull
PDF
/
Inventory: 3792
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Mating 59.0μin 1.50μm
Technical
Cable Opening 0.201 ~ 0.217 (5.10mm ~ 5.50mm)
Contact Resistance 3.6mOhm
Shell Size - Insert 306
Shell Finish Chrome
Current Rating 7A
Ingress Protection IP66/68 - Dust Tight, Water Resistant, Waterproof
Shielding Shielded
Orientation G
Contact Finish - Mating Gold
Fastening Type Push-Pull
Gender Receptacle
Color Silver
Number of Positions 6
Resistance 3.6mOhm
Connector Type Receptacle, Female Sockets
ECCN Code EAR99
Termination Solder Cup
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Backshell
Series 1K
Packaging Bulk
Operating Temperature -55°C~200°C
Physical
Backshell Material, Plating Brass, Chrome
Insert Material Polyetheretherketone (PEEK)
Shell Material Brass
Mounting Type Free Hanging (In-Line)
Contact Material Bronze
