PHG.1B.302.CLLD72
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Push Pull Connectors 2P SOLDER SCKT RECPT CABLE COLLET 7.2MM
PDF
/
Buying Options
Total Price: USD $37.14
Unit Price: USD $37.1448
≥1 USD $37.1448
≥10 USD $32.52656
≥100 USD $31.121024
≥500 USD $30.116944
≥1000 USD $29.113128
≥3000 USD $27.506864
Inventory: 79
Minimum: 1
-
+
Technical Details
Compliance
Ratings IP50
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Mating 59.0μin 1.50μm
Length 39.5mm
Diameter 12.5mm
Technical
Cable Opening 0.244 ~ 0.283 (6.20mm ~ 7.20mm)
Contact Style Socket
Shell Size - Insert 302
Shell Finish Chrome
Current Rating 15A
Ingress Protection IP50 - Dust Protected
Shielding Shielded
Orientation G
Contact Finish - Mating Gold
Fastening Type Push-Pull
Gender Female
Color Silver
Number of Positions 2
Connector Type Receptacle, Female Sockets
Termination Solder Cup
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Backshell
Series 1B
Packaging Bulk
Operating Temperature -55°C~250°C
Physical
Backshell Material, Plating Brass, Chrome
Insert Material Polyetheretherketone (PEEK)
Shell Material Brass
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Bronze
