PHC.0B.305.CLLD42Z
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Push Pull Connectors 5P SOLDER SCKT RECPT CABLE COLLET 4.2MM
PDF
/
Inventory: 3704
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Bronze
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material Brass
Insert Material Polyetheretherketone (PEEK)
Backshell Material, Plating Brass, Chrome
Technical
Operating Temperature -55°C~250°C
Packaging Bulk
Series 0B
Feature Backshell
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder Cup
Connector Type Receptacle, Female Sockets
Number of Positions 5
Color Silver
Gender Female
Fastening Type Push-Pull
Contact Finish - Mating Gold
Orientation C
Shielding Shielded
Ingress Protection IP50 - Dust Protected
Current Rating 6.5A
Shell Finish Chrome
Shell Size - Insert 305
Contact Style Socket
Cable Opening 0.126 ~ 0.165 (3.20mm ~ 4.20mm)
Dimensions
Diameter 9.5mm
Length 34.5mm
Contact Finish Thickness - Mating 59.0μin 1.50μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Ratings IP50
