PHB.3B.326.CYMD10Z
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Connector
PDF
/
Inventory: 6263
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Bronze
Mounting Type Free Hanging (In-Line)
Shell Material Brass
Insert Material Polyetheretherketone (PEEK)
Backshell Material, Plating Brass, Chrome
Technical
Operating Temperature -55°C~250°C
Packaging Bulk
Series 3B
Feature Backshell
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Receptacle, Female Sockets
Number of Positions 26
Color Silver
Gender Female
Fastening Type Push-Pull
Contact Finish - Mating Gold
Orientation B
Shielding Shielded
Ingress Protection IP50 - Dust Protected
Current Rating 4A
Shell Finish Chrome
Shell Size - Insert 326
Contact Style Socket
Cable Opening 0.362 ~ 0.394 (9.20mm ~ 10.00mm)
Dimensions
Diameter 19mm
Length 54.5mm
Contact Finish Thickness - Mating 59.0μin 1.50μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
