PHA.2B.312.CLLD62

LEMO
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Circular Connectors
Description Circular Push Pull Connectors 12P SOLDER SKT RECPT CABLE COLLET 6.2MM
PDF
/
Inventory: 6385
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Contact Material Bronze
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material Brass
Insert Material Polyetheretherketone (PEEK)
Backshell Material, Plating Brass, Chrome

Technical

Operating Temperature -55°C~250°C
Packaging Bulk
Series 2B
Feature Backshell
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder Cup
Connector Type Receptacle, Female Sockets
Number of Positions 12
Color Silver
Gender Female
Fastening Type Push-Pull
Contact Finish - Mating Gold
Orientation A
Shielding Shielded
Ingress Protection IP50 - Dust Protected
Current Rating 7A
Shell Finish Chrome
Shell Size - Insert 312
Contact Style Socket
Cable Opening 0.205 ~ 0.244 (5.20mm ~ 6.20mm)

Dimensions

Diameter 16.5mm
Length 46mm
Contact Finish Thickness - Mating 59.0μin 1.50μm

Compliance

Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Ratings IP50
