PFG.0B.305.CLLD56Z
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Push Pull Connectors 5P FIX RCPT W/2NUTS SOLD CBL COLET 5.6MM
PDF
/
Inventory: 8239
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings IP50
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Mating 59.0μin 1.50μm
Length 35.5mm
Diameter 12.4mm
Technical
Cable Opening 0.209 ~ 0.220 (5.30mm ~ 5.60mm)
Contact Style Socket
Shell Size - Insert 305
Shell Finish Chrome
Current Rating 6.5A
Ingress Protection IP50 - Dust Protected
Shielding Shielded
Orientation G
Contact Finish - Mating Gold
Fastening Type Push-Pull
Gender Female
Color Silver
Number of Positions 5
Connector Type Receptacle, Female Sockets
Termination Solder Cup
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Backshell
Series 0B
Packaging Bulk
Operating Temperature -55°C~250°C
Physical
Backshell Material, Plating Brass, Chrome
Insert Material Polyetheretherketone (PEEK)
Shell Material Brass
Mounting Feature Front and Rear Side Nut
Mounting Type Free Hanging (In-Line); Panel Mount
Mount Bulkhead, Free Hanging, Front, Panel, Rear Side Nut
Contact Material Bronze
