PCA.2C.306.CNLC32Z
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Connector
PDF
/
Inventory: 8328
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Bronze
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material Brass
Insert Material Polyamide (PA66), Nylon 6/6
Backshell Material, Plating Brass, Chrome
Technical
Operating Temperature -55°C~250°C
Packaging Bulk
Series 2C
Feature Backshell
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder Cup
Connector Type Receptacle, Female Sockets and Male Pins
Number of Positions 6
Color Silver
Fastening Type Push-Pull
Contact Finish - Mating Gold
Orientation Keyed
Ingress Protection IP50 - Dust Protected
Current Rating 12A
Shell Finish Chrome
Shell Size - Insert 306
Cable Opening 0.106 ~ 0.122 (2.70mm ~ 3.10mm)
Dimensions
Contact Finish Thickness - Mating 59.0μin 1.50μm
Compliance
RoHS Status ROHS3 Compliant
Ratings IP50
