PBN.1M.307.XLMT
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
POLARIZED Circular Connector
PDF
/
Inventory: 4514
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Dust Tight, IP68, Waterproof
RoHS Status ROHS3 Compliant
Dimensions
Contact Finish Thickness - Mating 59.0μin 1.50μm
Technical
Cable Opening 0.382 (9.70mm)
Environmental Characteristics FLUID/VIBRATION RESISTANT
Backshell Type SOLID
Empty Shell NO
Mating Information MULTIPLE MATING PARTS AVAILABLE
Shell Size - Insert 307
Shell Finish Nickel
Current Rating 7A
Ingress Protection IP68 - Dust Tight, Waterproof
Shielding Shielded
Orientation N (Normal)
Total Number of Contacts 7
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Gold
Fastening Type Threaded
Additional Feature POLARIZED
Applications Aerospace, Automotive, Aviation, Military
Color Gray
Number of Positions 7
Connector Type Receptacle, Female Sockets
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series 1M
Packaging Bulk
Operating Temperature -55°C~200°C
Physical
Insert Material Polyetheretherketone (PEEK)
Shell Material Aluminum Alloy
Mounting Feature Flange
Mounting Type Panel Mount
Mount Flanges, Panel
Contact Material Bronze
