HMG.0B.304.CLLP
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Push Pull Connectors FIXED RECEPTACLE NUT FIXING
PDF
/
Inventory: 3151
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Dust Tight, IP68, Waterproof
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Mating 59.0μin 1.50μm
Technical
Wire/Cable Gauge 22 AWG
Contact Gender Female
Voltage - Rated AC 1.1kV
Shell Size - Insert 304
Shell Finish Chrome
Current Rating 7A
Ingress Protection IP68 - Dust Tight, Waterproof
Shielding Shielded
Orientation G
Contact Finish - Mating Gold
Voltage - Rated DC 1.56kV
Fastening Type Push-Pull
Color Silver
Number of Positions 4
Connector Type Receptacle, Female Sockets
Termination Solder Cup
Part Status Active
Pbfree Code yes
Feature Ground, Potted
Series 0B
Packaging Bulk
Operating Temperature -20°C~100°C
Physical
Insert Material Polyetheretherketone (PEEK)
Shell Material Brass
Mounting Feature Bulkhead - Front Side Nut
Mounting Type Panel Mount
Mount Flanges, Front Side Nut, Panel
Contact Material Bronze
