FGJ.0B.302.CLLD52
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Push Pull Connectors Straight Plug Sz 0B
PDF
/
Buying Options
Total Price: USD $30.88
Unit Price: USD $30.8792
≥1 USD $30.8792
≥10 USD $27.04064
≥100 USD $25.872
≥500 USD $25.037408
≥1000 USD $24.202904
≥3000 USD $22.867574
Inventory: 228
Minimum: 1
-
+
Technical Details
Compliance
Ratings IP50
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Mating 59.0μin 1.50μm
Length 36mm
Diameter 9.5mm
Technical
Cable Opening 0.165 ~ 0.205 (4.20mm ~ 5.20mm)
Wire/Cable Gauge 22 AWG
Contact Style Socket
Contact Gender Female
Voltage - Rated AC 900V
Shell Size - Insert 302
Shell Finish Chrome
Current Rating 10A
Ingress Protection IP50 - Dust Protected
Shielding Shielded
Orientation J
Contact Finish - Mating Gold
Voltage - Rated DC 1.27kV
Fastening Type Push-Pull
Color Silver
Number of Positions 2
Connector Type Plug, Female Sockets
ECCN Code EAR99
Termination Solder Cup
Part Status Active
Feature Backshell
Series 0B
Packaging Bulk
Operating Temperature -55°C~250°C
Physical
Backshell Material, Plating Brass, Chrome
Insert Material Polyetheretherketone (PEEK)
Shell Material Brass
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Copper, Gold, Nickel
Contact Material Bronze
