FGG.1B.302.CYCD72Z
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Push Pull Connectors Straight plug Series 1B
PDF
/
Inventory: 5965
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material NOT SPECIFIED
Contact Plating Copper, Gold, Nickel
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material Brass
Insert Material Polyetheretherketone (PEEK)
Backshell Material, Plating Brass, Chrome
Technical
Operating Temperature -55°C~250°C
Packaging Bulk
Series 1B
Feature Backshell
Part Status Active
Termination Crimp
ECCN Code EAR99
Connector Type Plug, Male Pins
Number of Positions 2
Color Silver
Fastening Type Push-Pull
Voltage - Rated DC 2.4kV
Contact Finish - Mating Gold
Orientation G
Shielding Shielded
Ingress Protection IP50 - Dust Protected
Current Rating 15A
Shell Finish Chrome
Shell Size - Insert 302
Voltage - Rated AC 1.7kV
Contact Gender Male
Contact Style Pin
Wire Gauge (Max) 18 AWG
Wire Gauge (Min) 20 AWG
Cable Opening 0.244 ~ 0.283 (6.20mm ~ 7.20mm)
Dimensions
Diameter 12mm
Length 43mm
Contact Finish Thickness - Mating 39.4μin 1.00μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Ratings IP50
