FFP.2S.306.CLAC62
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Push Pull Connectors STRAIGHT PLUG CBL CLLT ANTI ROTATE
PDF
/
Inventory: 942
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings IP50
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Technical
Cable Opening 0.205 ~ 0.244 (5.20mm ~ 6.20mm)
Contact Gender Male
Shell Size - Insert 306
Shell Finish Chrome
Current Rating 12A
Ingress Protection IP50 - Dust Protected
Shielding Shielded
Orientation Keyed
Contact Finish - Mating Gold
Fastening Type Push-Pull
Color Silver
Number of Positions 6
Connector Type Plug, Female Sockets and Male Pins
Termination Solder Cup
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Backshell
Series 2S
Packaging Bulk
Operating Temperature -55°C~250°C
Physical
Backshell Material, Plating Brass, Chrome
Insert Material Polyetheretherketone (PEEK)
Shell Material Brass
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Copper, Gold, Nickel
Contact Material Brass, Bronze
