FFA.2C.306.CLAC57
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Push Pull Connectors STRAIGHT PLUG CABLE COLLET
PDF
/
Inventory: 9833
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings IP50
RoHS Status ROHS3 Compliant
Dimensions
Contact Finish Thickness - Mating 39.4μin 1.00μm
Technical
Cable Opening 0.205 ~ 0.220 (5.20mm ~ 5.60mm)
Shell Size - Insert 306
Shell Finish Chrome
Current Rating 12A
Ingress Protection IP50 - Dust Protected
Orientation Keyed
Contact Finish - Mating Gold
Fastening Type Push-Pull
Color Silver
Number of Positions 6
Connector Type Plug, Female Sockets and Male Pins
ECCN Code EAR99
Termination Solder Cup
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Backshell
Series 2C
Packaging Bulk
Operating Temperature -55°C~250°C
Physical
Backshell Material, Plating Brass, Chrome
Insert Material Polyetheretherketone (PEEK)
Shell Material Brass
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
