EXG.1B.302.HLN
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Push Pull Connectors ELB RECPT F. PR CRCT TWO NUTS
PDF
/
Buying Options
Total Price: USD $46.02
Unit Price: USD $46.024
≥1 USD $46.024
≥10 USD $42.23384
≥100 USD $40.609184
≥500 USD $39.255568
≥1000 USD $37.0898
Inventory: 173
Minimum: 1
-
+
Technical Details
Physical
Contact Material Bronze
Mount Bulkhead, Panel, Through Hole
Mounting Type Panel Mount, Through Hole, Right Angle
Mounting Feature Bulkhead - Front Side Nut
Shell Material Brass and Polyphenylene Sulfide (PPS)
Insert Material Polyetheretherketone (PEEK)
Technical
Operating Temperature -55°C~250°C
Packaging Bulk
Series 1B
Feature Ground
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder
ECCN Code EAR99
Connector Type Receptacle, Female Sockets
Number of Positions 2
Color Brown, Silver
Voltage - Rated 1.7kV
Fastening Type Push-Pull
Contact Finish - Mating Gold
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Current Rating (Amps) 4.5A
Total Number of Contacts 2
Orientation G
Shielding Shielded
Ingress Protection IP50 - Dust Protected
Current Rating 12A
Shell Finish Nickel
Shell Size - Insert 302
Contact Gender Female
Empty Shell NO
Backshell Type SOLID
Contact Style Socket
Environmental Characteristics CORROSION/MOISTURE RESISTANT
Coupling Type SNAP
Dimensions
Height 14mm
Length 27mm
Width 15mm
Contact Finish Thickness - Mating 59.0μin 1.50μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Ratings IP50
