ERA.3Y.415.CLL
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Connector
PDF
/
Inventory: 4399
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings IP50
RoHS Status ROHS3 Compliant
Dimensions
Contact Finish Thickness - Mating 78.7μin 2.00μm
Technical
Contact Gender Female
Voltage - Rated AC 16kV
Shell Size - Insert 415
Shell Finish Chrome
Current Rating 15A
Ingress Protection IP50 - Dust Protected
Contact Finish - Mating Gold
Voltage - Rated DC 22.5kV
Fastening Type Push-Pull
Color Silver
Number of Positions 1
Connector Type Receptacle, Female Sockets
Termination Solder Cup
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Backshell
Series 3Y
Packaging Bulk
Operating Temperature -55°C~230°C
Physical
Backshell Material, Plating Brass, Chrome
Insert Material Polyetheretherketone (PEEK)
Shell Material Brass
Mounting Feature Bulkhead - Rear Side Nut
Mounting Type Panel Mount
Mount Bulkhead, Panel, Rear Side Nut
Contact Material Beryllium Copper
