ENG.1B.305.CLL
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Push Pull Connectors FIXED RECEPTACLE W. EARTHING TAG
PDF
/
Buying Options
Total Price: USD $32.43
Unit Price: USD $32.428
≥1 USD $32.428
≥10 USD $28.39408
≥100 USD $27.167008
≥500 USD $26.290704
≥1000 USD $25.414312
≥3000 USD $24.012173
Inventory: 72
Minimum: 1
-
+
Technical Details
Compliance
Ratings IP50
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Mating 59.0μin 1.50μm
Length 23mm
Diameter 15.8mm
Technical
Contact Style Socket
Contact Gender Female
Shell Size - Insert 305
Shell Finish Chrome
Current Rating 9A
Ingress Protection IP50 - Dust Protected
Shielding Shielded
Orientation G
Contact Finish - Mating Gold
Fastening Type Push-Pull
Color Silver
Number of Positions 5
Connector Type Receptacle, Female Sockets
Termination Solder Cup
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Ground
Series 1B
Packaging Bulk
Operating Temperature -55°C~250°C
Physical
Insert Material Polyetheretherketone (PEEK)
Shell Material Brass
Mounting Feature Bulkhead - Rear Side Nut
Mounting Type Panel Mount
Mount Bulkhead, Panel, Rear Side Nut
Contact Material Bronze
