EHG.0B.307.CLL
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Push Pull Connectors FIXED RECEPTACLE NUT FIXING
PDF
/
Inventory: 2774
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Bronze
Mount Bulkhead, Panel, Rear Side Nut
Mounting Type Panel Mount
Mounting Feature Bulkhead - Rear Side Nut
Shell Material Brass
Insert Material Polyetheretherketone (PEEK)
Technical
Operating Temperature -55°C~250°C
Packaging Bulk
Series 0B
Pbfree Code yes
Part Status Active
Termination Solder Cup
Connector Type Receptacle, Female Sockets
Number of Positions 7
Color Silver
Fastening Type Push-Pull
Voltage - Rated DC 1.13kV
Contact Finish - Mating Gold
Orientation G
Wire/Cable Gauge 28 AWG
Contact Style Socket
Contact Gender Female
Voltage - Rated AC 800V
Shell Size - Insert 307
Shell Finish Chrome
Current Rating 2.5A
Ingress Protection IP50 - Dust Protected
Shielding Shielded
Compliance
Ratings IP50
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Mating 59.0μin 1.50μm
Length 19.5mm
Diameter 12.4mm
