EGJ.1B.302.CYC
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Connector
PDF
/
Inventory: 1446
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Mating 39.4μin 1.00μm
Length 23mm
Diameter 15.8mm
Technical
Contact Style Pin
Shell Size - Insert 302
Shell Finish Chrome
Current Rating 15A
Ingress Protection IP50 - Dust Protected
Shielding Shielded
Orientation J
Contact Finish - Mating Gold
Fastening Type Push-Pull
Gender Male
Color Silver
Number of Positions 2
Connector Type Receptacle, Male Pins
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series 1B
Packaging Bulk
Operating Temperature -55°C~250°C
Physical
Insert Material Polyetheretherketone (PEEK)
Shell Material Brass
Mounting Feature Bulkhead - Rear Side Nut
Mounting Type Panel Mount
Contact Material NOT SPECIFIED
