EGG.2B.318.CLL
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Push Pull Connectors FIXED RECEPTACLE NUT FIXING
PDF
/
Buying Options
Total Price: USD $67.58
Unit Price: USD $67.584
≥1 USD $67.584
≥10 USD $62.01976
≥100 USD $59.63408
≥500 USD $57.64616
≥1000 USD $54.465752
Inventory: 100
Minimum: 1
-
+
Technical Details
Physical
Contact Material Bronze
Mount Flanges, Panel, Rear Side Nut
Mounting Type Panel Mount
Mounting Feature Bulkhead - Rear Side Nut
Shell Material Brass
Insert Material Polyetheretherketone (PEEK)
Technical
Operating Temperature -55°C~250°C
Packaging Bulk
Series 2B
Contact Style Socket
Shell Size - Insert 318
Shell Finish Chrome
Current Rating 5.5A
Ingress Protection IP50 - Dust Protected
Shielding Shielded
Orientation G
Contact Finish - Mating Gold
Fastening Type Push-Pull
HTS Code 8536.69.40.20
Gender Female
Color Silver
Number of Positions 18
Connector Type Receptacle, Female Sockets
ECCN Code EAR99
Termination Solder Cup
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Compliance
Ratings IP50
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Mating 59.0μin 1.50μm
Length 26.7mm
Diameter 19.2mm
