EGG.2B.314.CLL
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Push Pull Connectors 14P STRAIGHT FEMALE PNL MNT SOLDER
PDF
/
Buying Options
Total Price: USD $58.33
Unit Price: USD $58.3264
≥1 USD $58.3264
≥10 USD $53.51984
≥100 USD $51.461696
≥500 USD $49.746048
≥1000 USD $47.001504
Inventory: 81
Minimum: 1
-
+
Technical Details
Physical
Contact Material Bronze
Mount Flanges, Panel, Rear Side Nut
Mounting Type Panel Mount
Mounting Feature Bulkhead - Rear Side Nut
Material Brass
Insert Material Polyetheretherketone (PEEK)
Technical
Operating Temperature -55°C~250°C
Packaging Bulk
Series 2B
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder Cup
ECCN Code EAR99
Connector Type Receptacle, Female Sockets
Number of Positions 14
Color Silver
Gender Receptacle
HTS Code 8536.69.40.20
Fastening Type Push-Pull
Contact Finish - Mating Gold
Orientation G
Shielding Shielded
Ingress Protection IP50 - Dust Protected
Current Rating 6.5A
Shell Finish Chrome
Shell Size - Insert 314
Contact Gender Female
Contact Style Socket
Wire/Cable Gauge 22 AWG
Dimensions
Diameter 19.2mm
Length 26.7mm
Contact Finish Thickness - Mating 59.0μin 1.50μm
Supply Chain
Factory Lead Time 15 Weeks
Compliance
Material Flammability Rating UL94 V-0
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Ratings IP50
