EGB.0B.307.CLL
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Push Pull Connectors STRAIGHT RECEPTACLE
PDF
/
Buying Options
Total Price: USD $21.4
Unit Price: USD $21.395377
≥1 USD $21.395377
≥10 USD $20.184322
≥100 USD $19.04181
≥500 USD $17.963975
≥1000 USD $16.947142
Inventory: 1727
Minimum: 1
-
+
Technical Details
Physical
Contact Material Bronze
Contact Plating Copper, Gold, Nickel
Mount Flanges, Panel, Rear Side Nut
Mounting Type Panel Mount
Mounting Feature Bulkhead - Rear Side Nut
Shell Material Brass
Insert Material Polyetheretherketone (PEEK)
Technical
Operating Temperature -55°C~250°C
Packaging Bulk
Series 0B
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder Cup
Connector Type Receptacle, Female Sockets
Number of Positions 7
Color Silver
Fastening Type Push-Pull
Contact Finish - Mating Gold
Orientation B
Shielding Shielded
Ingress Protection IP50 - Dust Protected
Current Rating 2.5A
Shell Finish Chrome
Shell Size - Insert 307
Contact Gender Female
Contact Style Socket
Dimensions
Diameter 12.4mm
Length 20.7mm
Contact Finish Thickness - Mating 59.0μin 1.50μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Ratings IP50
