EGA.1B.307.CYM
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Push Pull Connectors STRAIGHT RECEPTACLE
PDF
/
Inventory: 4165
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Bronze
Mount Bulkhead, Panel, Rear Side Nut
Mounting Type Panel Mount
Mounting Feature Bulkhead - Rear Side Nut
Shell Material Brass
Insert Material Polyetheretherketone (PEEK)
Technical
Operating Temperature -55°C~250°C
Packaging Bulk
Series 1B
Part Status Active
Termination Crimp
Connector Type Receptacle, Female Sockets
Number of Positions 7
Color Silver
Fastening Type Push-Pull
Contact Finish - Mating Gold
Orientation A
Shielding Shielded
Ingress Protection IP50 - Dust Protected
Current Rating 7A
Shell Finish Chrome
Shell Size - Insert 307
Contact Gender Female
Contact Style Socket
Dimensions
Diameter 15.8mm
Length 23mm
Contact Finish Thickness - Mating 59.0μin 1.50μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Ratings IP50
