EEG.4K.324.CLL
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Push Pull Connectors FIXED RECEPTACLE NUT FIXING
PDF
/
Inventory: 5374
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Bronze
Mount Flanges, Front Side Nut, Panel
Mounting Type Panel Mount
Mounting Feature Bulkhead - Front Side Nut
Shell Material Brass
Insert Material Polyetheretherketone (PEEK)
Technical
Operating Temperature -55°C~200°C
Packaging Bulk
Series 4K
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder Cup
Connector Type Receptacle, Female Sockets
Number of Positions 24
Color Silver
Fastening Type Push-Pull
Contact Finish - Mating Gold
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Total Number of Contacts 24
Orientation G
Shielding Shielded
Ingress Protection IP66/68 - Dust Tight, Water Resistant, Waterproof
Current Rating 7A
Shell Finish Chrome
Shell Size - Insert 324
Empty Shell NO
Backshell Type SOLID
Environmental Characteristics CORROSION/ENVIRONMENT/MOISTURE RESISTANT
Coupling Type SNAP
Dimensions
Contact Finish Thickness - Mating 59.0μin 1.50μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Ratings Dust Tight, IP66, Water Resistant, Waterproof
