EEG.0B.304.CLV
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
CONN RCPT FMALE 4POS GOLD SOLDER
PDF
/
Buying Options
Total Price: USD $32.01
Unit Price: USD $32.0144
≥1 USD $32.0144
≥10 USD $28.03416
≥100 USD $26.822752
≥500 USD $25.95736
≥1000 USD $25.092144
Inventory: 161
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Mating 59.0μin 1.50μm
Length 20.7mm
Diameter 12.5mm
Technical
Shell Size - Insert 304
Shell Finish Chrome
Current Rating 7A
Ingress Protection IP50 - Dust Protected
Shielding Shielded
Orientation G
Current Rating (Amps) 6A
Contact Finish - Mating Gold
Fastening Type Push-Pull
Gender Female
Color Silver
Number of Positions 4
Connector Type Receptacle, Female Sockets
ECCN Code EAR99
Termination Solder
Part Status Active
Pbfree Code yes
Series 0B
Packaging Bulk
Operating Temperature -55°C~250°C
Physical
Insert Material Polyetheretherketone (PEEK)
Shell Material Brass
Mounting Feature Bulkhead - Front Side Nut
Mounting Type Panel Mount, Through Hole, Right Angle
Contact Material Bronze
