EEG.0B.303.CLL
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Push Pull Connectors FIXED RECEPTACLE NUT FIXING
PDF
/
Buying Options
Total Price: USD $21.77
Unit Price: USD $21.7712
≥1 USD $21.7712
≥10 USD $19.06344
≥100 USD $18.239936
≥500 USD $17.651568
≥1000 USD $17.0632
≥3000 USD $16.121776
Inventory: 88
Minimum: 1
-
+
Technical Details
Compliance
Ratings IP50
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Mating 59.0μin 1.50μm
Length 20.7mm
Diameter 12.5mm
Technical
Coupling Type SNAP
Environmental Characteristics CORROSION/MOISTURE RESISTANT
Contact Style Socket
Backshell Type SOLID
Empty Shell NO
Contact Gender Female
Shell Size - Insert 303
Shell Finish Chrome
Current Rating 8A
Ingress Protection IP50 - Dust Protected
Shielding Shielded
Orientation G
Total Number of Contacts 3
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Gold
Fastening Type Push-Pull
Color Silver
Number of Positions 3
Connector Type Receptacle, Female Sockets
ECCN Code EAR99
Termination Solder Cup
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series 0B
Packaging Bulk
Operating Temperature -55°C~250°C
Physical
Insert Material Polyetheretherketone (PEEK)
Shell Material Brass
Mounting Feature Bulkhead - Front Side Nut
Mounting Type Panel Mount
Mount Flanges, Front Side Nut, Panel
Contact Plating Copper, Gold, Nickel
Contact Material Bronze
Supply Chain
Factory Lead Time 12 Weeks
