EEA.3B.318.CYM
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Connector
PDF
/
Inventory: 9119
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Shell Material Brass
Mounting Feature Bulkhead - Front Side Nut
Mounting Type Panel Mount
Contact Material Bronze
Insert Material Polyetheretherketone (PEEK)
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Mating 59.0μin 1.50μm
Length 30.7mm
Diameter 25mm
Technical
Contact Style Socket
Shell Size - Insert 318
Shell Finish Chrome
Current Rating 7A
Ingress Protection IP50 - Dust Protected
Shielding Shielded
Orientation A
Current Rating (Amps) 8A
Contact Finish - Mating Gold
Fastening Type Push-Pull
Gender Female
Color Silver
Number of Positions 18
Connector Type Receptacle, Female Sockets
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series 3B
Packaging Bulk
Operating Temperature -55°C~250°C
