ECJ.2B.314.CYC
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Push Pull Connectors Fixed Recpt Size 2B
PDF
/
Inventory: 7676
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings IP50
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Mating 39.4μin 1.00μm
Length 21.8mm
Diameter 19.2mm
Technical
Wire Gauge (Min) 26 AWG
Wire Gauge (Max) 22 AWG
Contact Style Pin
Contact Gender Male
Voltage - Rated AC 1.15kV
Shell Size - Insert 314
Shell Finish Chrome
Current Rating 6.5A
Ingress Protection IP50 - Dust Protected
Shielding Shielded
Orientation J
Contact Finish - Mating Gold
Voltage - Rated DC 1.63kV
Fastening Type Push-Pull
Color Silver
Number of Positions 14
Connector Type Receptacle, Male Pins
Termination Crimp
Part Status Active
Pbfree Code yes
Series 2B
Packaging Bulk
Operating Temperature -55°C~250°C
Physical
Insert Material Polyetheretherketone (PEEK)
Shell Material Brass
Mounting Feature Front and Rear Side Nut
Mounting Type Panel Mount
Mount Front, Panel, Rear Side Nut
Contact Plating Copper, Gold, Nickel
Contact Material NOT SPECIFIED
