ECJ.2B.302.CLD

LEMO
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Circular Connectors
Description Circular Push Pull Connectors RECEPTACLE W. NUT
PDF
/
Inventory: 4147
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Ratings IP50
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0

Dimensions

Contact Finish Thickness - Mating 39.4μin 1.00μm
Length 21.8mm
Diameter 19.2mm

Technical

Contact Style Pin
Contact Gender Male
Voltage - Rated AC 2.1kV
Shell Size - Insert 302
Shell Finish Chrome
Current Rating 25A
Ingress Protection IP50 - Dust Protected
Shielding Shielded
Orientation J
Contact Finish - Mating Gold
Voltage - Rated DC 2.97kV
Fastening Type Push-Pull
Color Silver
Number of Positions 2
Connector Type Receptacle, Male Pins
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series 2B
Packaging Bulk
Operating Temperature -55°C~250°C

Physical

Insert Material Polyetheretherketone (PEEK)
Shell Material Brass
Mounting Feature Front and Rear Side Nut
Mounting Type Panel Mount, Through Hole
Mount Panel, Through Hole
Contact Material NOT SPECIFIED
