ECJ.0B.304.CYB

LEMO
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Circular Connectors
Description Circular Push Pull Connectors 4P PANEL MNT RECEPT MALE CRIMP CONTACTS
PDF
/
Inventory: 8081
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Ratings IP50
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0

Dimensions

Contact Finish Thickness - Mating 39.4μin 1.00μm
Length 16.1mm
Diameter 12.4mm

Technical

Wire Gauge (Min) 32 AWG
Wire Gauge (Max) 28 AWG
Contact Style Pin
Contact Gender Male
Voltage - Rated AC 1.35kV
Shell Size - Insert 304
Shell Finish Chrome
Current Rating 7A
Ingress Protection IP50 - Dust Protected
Shielding Shielded
Orientation J
Contact Finish - Mating Gold
Voltage - Rated DC 1.91kV
Fastening Type Push-Pull
Color Silver
Number of Positions 4
Connector Type Receptacle, Male Pins
Termination Crimp
Part Status Active
Series 0B
Packaging Bulk
Operating Temperature -55°C~250°C

Physical

Insert Material Polyetheretherketone (PEEK)
Shell Material Brass
Mounting Feature Front and Rear Side Nut
Mounting Type Panel Mount
Mount Front, Panel, Rear Side Nut
Contact Material NOT SPECIFIED
