ECG.3B.316.CYP
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Connector
PDF
/
Inventory: 7973
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Bronze
Mount Bulkhead, Front, Panel, Rear Side Nut
Mounting Type Panel Mount
Mounting Feature Front and Rear Side Nut
Shell Material Brass
Insert Material Polyetheretherketone (PEEK)
Technical
Operating Temperature -55°C~250°C
Packaging Bulk
Series 3B
Part Status Active
Termination Crimp
Connector Type Receptacle, Female Sockets
Number of Positions 16
Color Silver
Gender Female
Fastening Type Push-Pull
Contact Finish - Mating Gold
Orientation G
Shielding Shielded
Ingress Protection IP50 - Dust Protected
Current Rating 8A
Shell Finish Chrome
Shell Size - Insert 316
Contact Style Socket
Dimensions
Diameter 25mm
Length 25.8mm
Contact Finish Thickness - Mating 59.0μin 1.50μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Ratings IP50
