ECG.3B.314.CLL
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Push Pull Connectors 14P FIXED RECEPTACLE SOLDER W/ 2 NUTS
PDF
/
Inventory: 5962
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings IP50
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Mating 59.0μin 1.50μm
Length 25.8mm
Diameter 25mm
Technical
Wire/Cable Gauge 22 AWG
Contact Style Socket
Contact Gender Female
Shell Size - Insert 314
Shell Finish Chrome
Current Rating 9A
Ingress Protection IP50 - Dust Protected
Shielding Shielded
Orientation G
Contact Finish - Mating Gold
Fastening Type Push-Pull
Color Silver
Number of Positions 14
Connector Type Receptacle, Female Sockets
Termination Solder Cup
Part Status Active
Series 3B
Packaging Bulk
Operating Temperature -55°C~250°C
Physical
Insert Material Polyetheretherketone (PEEK)
Shell Material Brass
Mounting Feature Front and Rear Side Nut
Mounting Type Panel Mount
Mount Bulkhead, Front, Panel, Rear Side Nut
Contact Material Bronze
