ECG.2B.310.CLN
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Conn Circular F 10 POS Solder ST Thru-Hole 10 Terminal 1 Port
PDF
/
Buying Options
Total Price: USD $51.78
Unit Price: USD $51.7792
≥1 USD $51.7792
≥10 USD $47.51648
≥100 USD $45.688896
≥500 USD $44.165792
≥1000 USD $41.729072
Inventory: 240
Minimum: 1
-
+
Technical Details
Compliance
Ratings IP50
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Mating 59.0μin 1.50μm
Length 21.8mm
Diameter 19.2mm
Technical
Coupling Type SNAP
Environmental Characteristics CORROSION/MOISTURE RESISTANT
Contact Style Socket
Backshell Type SOLID
Empty Shell NO
Contact Gender Female
Shell Size - Insert 310
Shell Finish Chrome
Current Rating 8A
Ingress Protection IP50 - Dust Protected
Shielding Shielded
Orientation G
Total Number of Contacts 10
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Gold
Fastening Type Push-Pull
HTS Code 8536.69.40.20
Color Silver
Number of Positions 10
Connector Type Receptacle, Female Sockets
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series 2B
Packaging Bulk
Operating Temperature -55°C~250°C
Physical
Insert Material Polyetheretherketone (PEEK)
Shell Material Brass
Mounting Feature Front and Rear Side Nut
Mounting Type Panel Mount, Through Hole
Mount Panel, Through Hole
Contact Material Bronze
Supply Chain
Factory Lead Time 12 Weeks
