ECG.2B.308.CLV

LEMO
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Circular Connectors
Description Circular Push Pull Connectors FIXED RECEPTACLE
PDF
/
Buying Options
Total Price: USD $56.22
Unit Price: USD $56.2232
≥1 USD $56.2232
≥10 USD $51.59264
≥100 USD $49.608416
≥500 USD $47.95472
≥1000 USD $45.309
Inventory: 95
Minimum: 1
-
+

Technical Details

Compliance

Ratings IP50
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0

Dimensions

Contact Finish Thickness - Mating 59.0μin 1.50μm
Length 21.8mm
Diameter 19.2mm

Technical

Coupling Type THREADED
Plating Nickel
Backshell Type SOLID
Empty Shell NO
Contact Gender Male
Shell Size - Insert 308
Shell Finish Chrome
Current Rating 6A
Ingress Protection IP50 - Dust Protected
Shielding Shielded
Orientation G
Total Number of Contacts 8
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Gold
Fastening Type Push-Pull
Additional Feature POLARIZED
Gender Female
Color Silver
Number of Positions 8
Connector Type Receptacle, Female Sockets
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series 2B
Packaging Bulk
Operating Temperature -55°C~250°C

Physical

Insert Material Polyetheretherketone (PEEK)
Shell Material Brass
Mounting Feature Front and Rear Side Nut
Mounting Type Panel Mount, Through Hole, Right Angle
Mount Panel, Through Hole
Contact Plating Gold, Nickel
Contact Material Bronze
