ECG.1B.304.CLV

LEMO
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Circular Connectors
Description Circular Push Pull Connectors 4P FEMALE R/A PCB R/A PANEL MOUNT
PDF
/
Buying Options
Total Price: USD $37.56
Unit Price: USD $37.5584
≥1 USD $37.5584
≥10 USD $32.88648
≥100 USD $31.46528
≥500 USD $30.450288
≥1000 USD $29.435296
≥3000 USD $27.811274
Inventory: 150
Minimum: 1
-
+

Technical Details

Technical

Shell Finish Chrome
Shell Size - Insert 304
Voltage - Rated AC 630V
Contact Gender Female
Empty Shell NO
Backshell Type SOLID
Contact Resistance 4.1mOhm
Environmental Characteristics CORROSION/MOISTURE RESISTANT
Coupling Type SNAP
Current Rating 10A
Ingress Protection IP50 - Dust Protected
Shielding Shielded
Orientation G
Total Number of Contacts 4
Current Rating (Amps) 6A
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Gold
Fastening Type Push-Pull
Gender Receptacle
Color Silver
Number of Positions 4
Resistance 4.1mOhm
Connector Type Receptacle, Female Sockets
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series 1B
Packaging Bulk
Operating Temperature -55°C~250°C

Dimensions

Diameter 15.8mm
Length 19.8mm
Contact Finish Thickness - Mating 59.0μin 1.50μm

Compliance

Material Flammability Rating UL94 V-0
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Ratings IP50

Physical

Insert Material Polyetheretherketone (PEEK)
Material Brass
Mounting Feature Front and Rear Side Nut
Mounting Type Panel Mount, Through Hole, Right Angle
Mount Panel, Through Hole
Contact Material Bronze

Supply Chain

Factory Lead Time 12 Weeks
