ECG.1B.302.CLV
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Push Pull Connectors FIXED RECEPTACLE
PDF
/
Buying Options
Total Price: USD $33.24
Unit Price: USD $33.237336
≥1 USD $33.237336
≥10 USD $31.355981
≥100 USD $29.581115
≥500 USD $27.906703
≥1000 USD $26.327084
Inventory: 950
Minimum: 1
-
+
Technical Details
Physical
Contact Material Bronze
Mount Panel, Through Hole
Mounting Type Panel Mount, Through Hole, Right Angle
Mounting Feature Front and Rear Side Nut
Shell Material Brass
Insert Material Polyetheretherketone (PEEK)
Technical
Operating Temperature -55°C~250°C
Packaging Bulk
Series 1B
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Receptacle, Female Sockets
Number of Positions 2
Color Silver
Gender Female
Fastening Type Push-Pull
Contact Finish - Mating Gold
Orientation G
Shielding Shielded
Ingress Protection IP50 - Dust Protected
Current Rating 12A
Shell Finish Chrome
Shell Size - Insert 302
Dimensions
Diameter 15.8mm
Length 19.8mm
Contact Finish Thickness - Mating 59.0μin 1.50μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Ratings IP50
