ECC.0B.305.CLV
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Push Pull Connectors RECEPTACLE W. NUT
PDF
/
Inventory: 1774
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Bronze
Mount Panel, Through Hole
Mounting Type Panel Mount, Through Hole, Right Angle
Mounting Feature Front and Rear Side Nut
Shell Material Brass
Insert Material Polyetheretherketone (PEEK)
Technical
Operating Temperature -55°C~250°C
Packaging Bulk
Series 0B
Pbfree Code yes
Part Status Active
Termination Solder
Connector Type Receptacle, Female Sockets
Number of Positions 5
Color Silver
Gender Female
Fastening Type Push-Pull
Contact Finish - Mating Gold
Orientation C
Shielding Shielded
Ingress Protection IP50 - Dust Protected
Current Rating 6A
Shell Finish Chrome
Shell Size - Insert 305
Dimensions
Diameter 12.4mm
Length 16.1mm
Contact Finish Thickness - Mating 59.0μin 1.50μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Ratings IP50
